Product information

Designed specifically for use with the PZ©turn quick-change system, the heads are matched to the shanks to ensure accurate and efficient machining.

- Quick-change system with only one clamping screw
- Cutting head suitable for metric and inch shank
- Highest level of precision even in terms of center height
- Multipurpose for all sliding head and multispindle lathes
- Inner coolant through holdert
- Optimal accessibility when changing inserts
- No loss of stability compare to mono-block tools

Variants

product name WSP-shape WSP-Size Interface F-measured (WTA) L (Length from plan system) LF KAPR (angle) WSP-voltage ART.-NR:
PZ16-K-PDJNR-0826-11 DN 1104 PZ16 8 26 93 Kniehebel mit Zwischenlage E00019660
PZ16-K-PDJNL-1226-11 DN 1104 PZ16 12 26 93 Kniehebel mit Zwischenlage E00019661
PZ16-K-PDNNN-0026-11 DN 1104 PZ16 26 Kniehebel mit Zwischenlage E00020795
PZ20-K-PDJNL-1736-15 DN 1506 PZ20 17 36 93 Kniehebel mit Zwischenlage E00024681
PZ20-K-PDJNR-1236-15 DN 1506 PZ20 12 36 93 Kniehebel mit Zwischenlage E00024981
PZ20-K-PDJNR-1226-11 DN 1104 PZ20 12 25 93 Kniehebel mit Zwischenlage E00025032
PZ20-K-PDJNL-1725-11 DN 1104 PZ20 17 25 93 Kniehebel mit Zwischenlage E00025033
PZ16-K-PDJNR-0835-15 DN 1506 PZ16 8 35 93 Kniehebel mit Zwischenlage E00027618
